Widely used in various industries, including automotive, electronics, consumer goods, and medical devices. They offer advantages such as efficient use of floor space, ease of operation, and versatility in producing a wide range of plastic parts.
Type | Unit | LZ-450 | ||||
Injection unit | Screw dia. | mm | 25 | 30 | 35 | |
Injection pressure | kg/cm2 | 2150 | 1740 | 1280 | ||
Theoretical shot volume | cm3 | 60 | 85 | 115 | ||
Shot weight | g | 53 | 76 | 101 | ||
oz | 1.9 | 2.7 | 3.6 | |||
Injection rate | cm3/sec | 63 | 91 | 125 | ||
Screw stroke | mm | 120 | ||||
Screw rate | rpm | 0-350 | ||||
Injection speed | mm/s | 130 | ||||
Temperature section(zone) | - | 5 | ||||
Clamping unit | Clamping force | tons | 45 | |||
Opening force | tons | 4.3 | ||||
Fixed table | Table size | mm | 530*380 | |||
Tie bar | mm | 390*240 | ||||
Min. mold thickness | mm | 160 | ||||
Opening stroke | mm | 200 | ||||
Opening daylight | mm | 360 | ||||
Electric unit | Ejector force | tons | 1.5 | |||
Ejector stroke | mm | 37 | ||||
Max. pressure | kg/cm2 | 140 | ||||
Oil tank volume | liters | 120 | ||||
Cooling water volume | liters/hr | 50 | ||||
System Motor | kw | 5.5 | ||||
Heater | kw | 5.8 | ||||
Total wattage | kw | 11.3 | ||||
Others | Machine weight | tons | 1.5 | |||
Machine size | m | L1.9*W1.1*H3.0 |
Small footprint, user-friendly operation, strong stability, high production efficiency, wide applicability, easy maintenance, and environmental friendliness. These features make them widely used in various industries.
